中空玻璃生产线的调试方法
Debugging method of insulating glass production line
1 将中空玻璃生产线轻置于安装位,正确摆放生产线各段的位置次序.
1 place the insulating glass production line gently at the installation position, and correctly place the position order of each section of the production line
2 机身调平.调整机器底座上调平螺栓高度,使传送辊、支撑尼龙轮支撑面等高,斜架上的背靠轮共面,各段相对平行,然后锁紧螺母.
2 fuselage leveling Adjust the height of the leveling bolt on the machine base so that the supporting surfaces of the transfer roller and the supporting nylon wheel are equal in height, the back-up wheels on the inclined frame are coplanar, and each section is relatively parallel, and then lock the nut
3 将各段间需联接的部位联接紧固,联接好由入料段到清洗干燥段的传动链条.正确摆放风机及水箱,并按水路、风路系统图接好风管、水管.
3 connect and fasten the parts to be connected between the sections, and connect the transmission chain from the feeding section to the cleaning and drying section Place the fan and water tank correctly, and connect the air pipe and water pipe according to the water and air system diagram

4 一体检查机器所有紧固件连接处是否因运输震动而松动,并逐件紧固(特别是各接线端子连接处是否松动).
4 check whether all fastener connections of the machine are loose due to transportation vibration, and tighten them one by one (especially whether the connection of each wiring terminal is loose)
5 接地线用截面积不小于4平方毫米的软铜心黄绿绝缘线,接地电阻不大于4 欧姆.
5 the soft copper core yellow green insulated wire with a cross-sectional area of not less than 4mm2 shall be used for the grounding wire, and the grounding resistance shall not be greater than 4 ohms
6 接通气源,检查管路是否通畅,有无破损.气源压力要求0.6~0.8Mpa.
6 connect the air source and check whether the pipeline is smooth and damaged The air supply pressure shall be 0.6~0.8mpa
7 接通电源,试验各电机的旋转方向是否正确,各段传动链轮是否灵活、平稳.
7. Turn on the power supply and test whether the rotation direction of each motor is correct and whether the drive sprocket of each section is flexible and stable
8 整机清洁,整理工作区间.
8. Clean the whole machine and arrange the working area
