中空玻璃的组成部分：
Components of insulating glass:
1、边缘密封系统。在目前国际市场上，公认的中空玻璃边缘密封系统有两种：一种是传统的冷边密封系统（槽铝式），一种是以美国Swiggle胶条为代表的暖边密封系统（复合胶条式）。由于传统铝槽式中空玻璃产品在国际和国内应用的时间较长，因而被很多人认可，而暖边系统1997年才开始在国内推广，产品还没有被人们广泛认识。
1. Edge sealing system. In the current international market, there are two recognized insulating glass edge sealing systems: one is the traditional cold edge sealing system (slot aluminum type), and the other is the warm edge sealing system (composite adhesive strip type), represented by American swiggle adhesive strip. Because the traditional aluminum trough insulating glass products have been used for a long time at home and abroad, they have been recognized by many people. However, the warm edge system was only promoted in China in 1997, and the products have not been widely recognized.
2、空间间隔层和气体。在中空玻璃的间隔层中，为了保证中空玻璃的性能，间隔层气体是干燥的。内部气体可以是干燥空气、氩气或其他特殊气体。
2. Space compartments and gases. In the spacer layer of insulating glass, firstly, in order to ensure the performance of insulating glass, the gas in the spacer layer is dry. The internal gas can be dry air, argon or other special gases.
3、构成中空玻璃的原片玻璃。这些玻璃可以是普通玻璃、夹层玻璃、阳光控制玻璃等等。由于采用的原片玻璃不同，中空玻璃的作用及使用地点也可以不同。而且由于要求不同，可以采用两层，三层或多层原片玻璃。
3. The original sheet glass that forms the insulating glass. These glasses can be ordinary glass, laminated glass, sunlight control glass, etc. Due to the different original glass, the function and place of use of insulating glass can also be different. Moreover, due to different requirements, two, three or more layers of original glass can be used.
中空玻璃的生产流程：
Production process of insulating glass:
整个中空玻璃的加工流程简单的描述就是玻璃裁切→磨边→清洗干燥→制框→灌装干燥剂→涂布丁基胶→上框→合片压片→封胶→固化。看似过程十分的简单并且中空玻璃的制作也十分的轻松，但是在我们实际生产操作中也是十分需要技术和耐心的。
The simple description of the whole insulating glass processing process is glass cutting → edging → cleaning and drying → frame making → filling desiccant → coating butyl rubber → upper frame → closing and pressing → sealing → curing. It seems that the process is very simple and the production of insulating glass is also very easy, but it also needs technology and patience in our actual production and operation.

关于充气中空玻璃的生产控制：
Production control of inflatable insulating glass:
充气中空玻璃的生产过程控制概念是，为确保充气中空玻璃生产过程处于受控状态，对影响充气浓度质量的生产过程所采取的作业技术和生产过程的分析、诊断和实时监控。它的作用在于对生产过程的质量控制进行系统安排，对直接或间接影响过程质量的因素进行**控制并制定实施控制计划，确保过程质量。氩气是无色无味气体，其充气浓度不易测量。目前的测试方法大体可以分为两种：
The production process control concept of inflatable insulating glass is the analysis, diagnosis and real-time monitoring of the operation technology and production process that affect the quality of inflatable concentration in order to ensure that the production process of inflatable insulating glass is under control. Its role is to systematically arrange the quality control of the production process, control the factors that directly or indirectly affect the process quality, and formulate and implement the control plan to ensure the process quality. Argon is a colorless and odorless gas, and its inflation concentration is difficult to measure. The current testing methods can be roughly divided into two types:
（1）传感器对从排气孔所收集的气体与所设置的气体浓度相比较，以判断是否达到要求。
(1) The sensor compares the gas collected from the exhaust hole with the set gas concentration to judge whether it meets the requirements.
（2）传感器对排气孔所收集的气体与所设置的气体浓度进行动态比较并给出浓度、气压和流速等实时曲线，不但从浓度上判断而且从曲线形状上判断，充气的实际浓度。
(2) The sensor dynamically compares the gas collected by the exhaust hole with the set gas concentration and gives the real-time curves of concentration, pressure and flow rate. It can judge the actual concentration of inflation not only from the concentration but also from the curve shape.
二者相比，由于-*二种方法不仅仅是两个值的比较，而是对整个充气过程的描述，是目前充气过程实时监控的的生产控制手段。
Compared with the two, the - * two methods are not only the comparison of two values, but also the description of the whole inflation process. They are advanced production control means for real-time monitoring of the inflation process at present.
