将成卷的基材，如：纸张、布匹、皮革、铝箔、塑料薄膜等，涂上一层特定功能的胶、涂料或油墨等，并烘干后收卷。

Apply a layer of specific functional adhesive, coating or ink to the rolled substrate, such as paper, cloth, leather, aluminum foil, plastic film, etc., and dry before winding.

自动涂布机的工作原理：用于网印制版的自动涂布机的工作原理是相同的，但其性能根据不同的机型及不同的生产厂家而不同。丝网涂布机在垂直的机架上都设有能夹紧网框的装置。丝网区的前后是水平的涂布机构，这个涂布机构由涂布槽，以及控制涂布槽角度和压力的机械部件或气动部件组成。

The working principle of an automatic coating machine: The working principle of an automatic coating machine used for screen printing and plate making is the same, but its performance varies depending on different models and manufacturers. The screen coating machine is equipped with a device on the vertical frame that can clamp the mesh frame. The front and back of the screen area are horizontal coating mechanisms, which consist of coating grooves and mechanical or pneumatic components that control the angle and pressure of the coating grooves.

涂布机涂布前，将清洁的，绷好网的网版从涂布机前面装入，有的机型也可从侧面装入网版。在为大幅面网框设计的机型中，侧面装版更为常见，因为网框大且笨重，侧面装版，可使抬升量和搬动量小一些。在自动丝网涂布机与其他自动丝网处理设备（如清洁设备、再生设备、干燥装置和显影机）联机运行时，从侧面装版更为便利。

Before coating with the coating machine, load the clean and tensioned mesh from the front of the coating machine, and some models can also load the mesh from the side. In models designed for large format mesh frames, side mounting is more common because the mesh frame is large and bulky, and side mounting can reduce lifting and handling. When the automatic screen coating machine is operated in conjunction with other automatic screen processing equipment (such as cleaning equipment, regeneration equipment, drying device, and developer), it is more convenient to install plates from the side.

自动涂布机的用途：适用于鞋材、电子行业、海棉、EVA、PE、布料等涂胶。

The purpose of the automatic coating machine is to apply glue to shoe materials, electronics industry, sponge, EVA, PE, fabrics, etc.

涂布机张力系统：

Coating machine tension system:

1、工艺要求：涂布机需要将胶或者油墨类物质均匀粘连在铝箔、塑料薄膜或者布料纺织品表面，对涂布工艺要求比较高，不仅要求涂布高度均匀而且要能够实现高速不停机换卷以提高生产效率；

1. Process requirements: The coating machine needs to uniformly adhere adhesive or ink substances to the surface of aluminum foil, plastic film, or fabric textiles. The coating process requires high requirements, not only requiring uniform coating height but also achieving high-speed non-stop roll changing to improve production efficiency;

2、方案优点：由变频器完成各级张力控制，使用张力传感器实现张力控制，系统简单且稳定。用PLC或同步控制器来控制驱动辊变频器速度，同时作为其他变频器的线速度信号；S350闭环张力控制（有感矢量控制）轻松实现加减速过程中的张力恒定，节省安装张力；辊的空间，降低机械成本，同时控制确保了涂布效果高度均匀。双工位收放卷具有预驱动功能，可满足高速不停机自动换卷、提高生产效率的需求。同时准确的收卷控制可以避免菜心式不良收卷，使收卷效果更好。

2. Advantages of the solution: The tension control at all levels is completed by the frequency converter, and the tension control is achieved using a tension sensor. The system is simple and stable. Use PLC or synchronous controller to control the speed of the drive roller frequency converter, while serving as the linear speed signal for other frequency converters; S350 closed-loop tension control (inductive vector control) easily achieves constant tension during acceleration and deceleration, saving installation tension; The space of the rollers reduces mechanical costs, while controlling to ensure a highly uniform coating effect. The dual station winding and unwinding system has a pre drive function, which can meet the needs of high-speed automatic roll changing without stopping the machine and improve production efficiency. Accurate winding control can avoid poor winding of vegetable hearts and improve the winding effect.
