造成双组份打胶机打胶不饱满的原因有哪些?
时间:2019-09-10 来源:http://www.jncsjx.com/ 发布人:昌盛机械
双组份打胶机打胶不饱满,要怎么解决?其实我们的双组份打胶机出现这个问题,主要是有以下几种情况导致的:
How to solve the problem of insufficient gluing of two-component gluing machine? In fact, the problem of our two-component glue punch is mainly caused by the following circumstances:
一、打胶速度过快
1. Gluing speed is too fast
有的客户为了加快自己的生产节奏追赶生产计划,将打胶速度认为调整的过快,导致胶体还没有完全达到合格标准机头就已经移动到下一个位置进行打胶操作了。
Some customers in order to speed up their production rhythm to catch up with the production plan, the gluing speed is considered to be too fast to adjust, resulting in the colloid has not fully met the qualified standard head has moved to the next position for gluing operation.
如果我们需要加快打胶的速度调整了打胶机的移动参数的话,那么我们对应的也应该对供胶系统也进行相应的设置,比如这时候我们就需要加大供胶压力,增大打胶机的出胶速度来配合对象的移动速度的增加。
If we need to speed up the gluing speed and adjust the moving parameters of the gluing machine, then we should also set up the gluing system accordingly. For example, at this time, we need to increase the pressure of the gluing machine, increase the speed of the gluing machine to match the increase of the moving speed of the object.
如果我们仅仅是单独的增加了打胶机的移动速度而没有对压力进行调节的话就很有可能出现打胶不饱满的情况发生。
If we simply increase the speed of the glue machine without adjusting the pressure, it is likely that the glue will not be full.
二、供胶压力不足
2. Insufficient supply pressure
这个情况其实在前一种情况的已经进行过描述了,即便你没有对打胶机的移动速度进行调节也出现了打胶不饱满的情况,那么也有可能是供胶压力过小导致的。这时候我们仅仅需要调整供胶压力即可完美的解决这个问题的发生。
In fact, this situation has been described in the former case. Even if you do not adjust the speed of the glue machine, there is a situation that the glue is not full, then it may also be caused by too little glue supply pressure. At this time, we only need to adjust the supply pressure to solve this problem perfectly.
三、机头感应器损坏
3. Damage of nose inductor
这种情况非常的少见,但是也不排除这种情况的发生。在我们的打胶机机头有一个对铝条深浅进行探测的感应器,如果发现双组份铝隔条过深或者过浅的时候他会自动的调整移动的移动速度以及供胶压力(自动调整幅度是小范围内的)。如果我们的铝条本身就深浅不一,在加上我们的感应器损坏的坏就会发生这种情况!
This situation is very rare, but it can not be ruled out. There is a sensor to detect the depth of aluminium bar in the head of our gluing machine. If it is found that the two-component aluminium bar is too deep or too shallow, it will automatically adjust the moving speed and the gluing pressure (the automatic adjustment range is small). If our aluminium bars are different in depth, this will happen if our sensors are damaged.
好了,今天的精彩内容就先给大家介绍到这里了,欢迎大家收藏我们的网站:http://www.jncsjx.com,我们将会定期更新更多的精彩内容!大家搜索关键词:双组份打胶机,这样也可以找到我们!谢谢大家的支持!
Well, today's wonderful content is introduced to you first, welcome to collect our website: http://www.jncsjx.com, we will update more wonderful content regularly! Everyone searches for keywords: two-component glue machine, so you can find us! Thank you for your support!造成双组份打胶机打胶不饱满的原因有哪些?
